・Frequency Step Setting
・High &Low Power Switchover
・Battery Saving
・VOX Function
・Wide/Narrow Band Selection
・Auto-Back Light
・Dual Band Standby
・Time-out Timer (TOT)
・50 CTCSS and 104 DCS Codes
・Voice Prompt
・ANI Code
・PC or Manual Program
・DTMF Code
・PTT-ID
・ATUO Keypad Lock
・Busy Channel Lock Function
・Dual Band, Dual Display and Dual Standby
・Emergency Alarm
・Priory Scanning Function
・Relay Forwarding Confirmed (1750 HZ)
・Low Battery Warning
・U/V Cross Band Dual Watch
Frequency Range:136.00-174.00MHz/400.00-480.00MHz
Storage Channel:128
Step Frequency:2.5/5/6.25/10/12.5/20/25KHz
Rated voltage:DC 7.4V
Frequency Stability:±2.5ppm
Work Temperature:-20 ℃ to +60℃
Battery Capacity:H-1800mAh(Li-ion Battery)
Battery Life:About 12Hours
Frequency Combination:PLL frequency synthesis
Antenna Impedance:50Ω
Wok Mode:Same Frequency simplex Operation or Different Frequency
simplex Operation
Dimension:110x58x32 mm (Excluded Antenna) |
Transmitter
Output Power:5W/1W(VHF)，4W/1W(UHF)
Modulation Mode(W/N Band):FM(F3E)
Maximum Frequency Deviation(W/N Band):≤5KHz,<2.5KHz(N)
Spurious Power:≤7.5µW
Adjacent channel power:≤-65dB/≤-60dB
Audio Distortion:<5%
SNR(W/N Band):≥-45dB/≥-40dB
CTSCC/DCS Frequency Deviation(W/N Band):0.7±0.1KHz(W), 0.4±0.1KHz(N)
Modulation Sensitivity:8-12mV
Transmitting Current:≤1500mA
Receiver
Sensitivity:＜0.20µV (12dB SINAD)
Audio Power:1W
Inter modulation Interference Resistance:≥65dB(W), ≥55dB(N)
Adjacent channel Sensitivity (W/N Band):≥65dB(W), ≥55dB(N)
Audio Distortion:5%
Receiving Current:≤ 380mA |
